Stock #:
0101-8075
Catalogue #:
THT300/BLK
| 2 part gland body sealing ring. | |
| Available Options | 5 Pole Option Available |
|---|---|
| Cable Size Range | 5 - 13mm² |
| Colour | Black |
| Compliance | CE, RoHS, ENEC |
| Conductor Size | 4mm² |
| Current Rating | 32A |
| Diameter | 26.5mm |
| Dimensions | (L)115 mm x (Dia)26.5 mm |
| Guarantee | 1 Year |
| IP Rating | IP68 |
| Length | 115mm |
| Logistics Partner | NONE |
| Material | PA66/TPE |
| Maximum Cable Diameter | 13mm |
| Maximum Operating Temperature | 125°C |
| Minimum Diameter | 5mm |
| Minimum Operating Temperature | -40°C |
| Number Of Poles | 3 Pole |
| Number Of Terminals | 3 |
| Packaging Types | Bag |
| Product Range | TeeTube |
| Punchout | No |
| Similar Stock | No |
| Suitable For | Indoors or Outdoors, Underground and Underwater |
| Terminal Type | Screw |
| Type | In Line |
| Unspsc V13 | 39121332 |
| Unspsc V18 | 39121332 |
| Unspsc V22 | 39121332 |
| Unspsc V24 | 39121332 |
| Voltage Rating | 450V |
| Weight | 0.052kg |
