Stock #:
2264-5090
Catalogue #:
CL800
| Low Impedance [LoZ] mode for identifying and eliminating ghost or stray voltage. CAT IV 600V, CAT III 1000V, Class 2, double insulation safety rating. Built to withstand a 6.6ft [2m] drop. Low battery indicator and easily accessible battery compartment. Operating temp: 32°F to 104°F [0°C to 40°C]. Operating altitude to 6562ft [2000m]. Includes carrying pouch, test leads, thermocouple with adaptor and batteries. Meets requirements for use in basic and controlled electromagnetic environments such as residential, office and light industrial locations. | |
| Ac Current Measurement | 600A |
|---|---|
| Ac Voltage Measurement | 1000V AC |
| Auto Ranging | Yes |
| Battery Level Indicator | Yes |
| Battery Size | AAA |
| Battery Type | Alkaline |
| Capacitance Measurement | 6000µF |
| Compliance | CE |
| Continuity Check | Yes |
| Data Hold | Yes |
| Dc Current Measurement | 600A DC |
| Dc Voltage Measurement | 1000V DC |
| Depth | 39mm |
| Dimensions | (H)231 mm x (W)97 mm x (D)39 mm |
| Display Count | 6000 |
| Display Type | LCD |
| Frequency Measurement | 1 Hz - 500 kHz |
| Guarantee | 2 Years |
| Height | 231mm |
| IP Rating | IP40 |
| Logistics Partner | NONE |
| Non Contact Measurement | Yes |
| Number Of Batteries | 2 |
| Packaging Types | Pack |
| Punchout | No |
| Resistance Measurement | 60MΩ |
| Safety Range | CAT IV 600V |
| Similar Stock | No |
| Supplied With | Carrying Case, Test Leads, Thermocouple with Adaptor and Batteries |
| Temperature Range | -26 - 538°C |
| Unspsc V13 | 41113678 |
| Unspsc V18 | 41113678 |
| Unspsc V22 | 41113678 |
| Unspsc V24 | 41113678 |
| Video Url | https://www.youtube.com/embed/jUzWiDAX524 |
| Weight | 0.7kg |
| Width | 97mm |
