Stock #:
0338-4589
Catalogue #:
XS5DB
| Recommended back box depth: 25mm. Maximum load rating: 13A. Intended applications: Domestic power supply. | |
| Available Options | Alternative Finishes Available |
|---|---|
| Colour | Chrome |
| Compliance | CE |
| Current Rating | 13A |
| Depth | 31mm |
| Dimensions | (H)88 mm x (W)148 mm x (D)31 mm |
| Finish | Matt |
| Fixing Centres | 120.6mm |
| Guarantee | 10 Years |
| Height | 88mm |
| Insert Colours | Polished Stainless Steel/Black |
| Logistics Partner | NONE |
| Material | Steel |
| Mounting | Wall |
| Mounting Depth | 25mm |
| Number Of Gangs | 2 |
| Number Of Poles | Double Pole |
| Number Of Terminals | 4 |
| Obsolete Iso | 2021-12-16 |
| Packaging Types | Pack |
| Shape | Curved Edge |
| Similar Stock | No |
| Standards | BS 1363-2 |
| Switched Unswitched | Switched |
| Terminal Capacity Earth | 4 x 2.5mm² |
| Terminal Capacity Live Neutral | 4 x 2.5mm² |
| Unspsc | 39122200 |
| Unspsc V13 | 39121406 |
| Unspsc V18 | 39121406 |
| Unspsc V22 | 39121406 |
| Voltage Rating | 250V |
| Weight | 0.24kg |
| Width | 148mm |
